Are you frustrated by sluggish, outdated machines that stall your projects? The Intel LGA1151 6/8/9 th gen Embedded Industrial PC With Intel Z390 Chipest delivers the speed and reliability you need for demanding industrial applications, offering a compact yet powerful solution that keeps your workflow moving forward.
Intel LGA1151 6/8/9 th gen Embedded Industrial PC With Intel Z390 Chipest - the answer to slow, unreliable computing
This industrial PC tackles the bottleneck of old hardware by providing a modern Intel processor and robust components that handle intensive tasks with ease. When your system lags, productivity suffers and deadlines slip. By upgrading to this board, you gain a fast, stable platform that supports both Windows 10 and Linux, ensuring you can run any required software without compromise.
Usages of Intel LGA1151 6/8/9 th gen Embedded Industrial PC With Intel Z390 Chipest
Ideal for automation controllers, digital signage, edge computing, and rugged field deployments, this PC fits into desktop or embedded installations where space is limited but performance cannot be sacrificed.
Benefits of Intel LGA1151 6/8/9 th gen Embedded Industrial PC With Intel Z390 Chipest
You enjoy lightning-fast processing for real-time data, up to 64 GB of RAM for multitasking, flexible storage options for large datasets, dual-display output for richer visualisation, and reliable power handling from 9 V to 36 V. The built-in POE ports simplify network cabling, while the rugged aluminium chassis endures harsh environments, giving you peace of mind and lower total cost of ownership.
Key Features of Intel LGA1151 6/8/9 th gen Embedded Industrial PC With Intel Z390 Chipest
- Intel LGA1151 6/8/9 th gen processor
- Intel Z390 Chipset
- 2 × SODDR4 slots, max 64 GB RAM
- 1 × 2.5 inch HDD, 1 × MSATA, 1 × M.2/SSD
- 6 × USB 3.0, 2 × USB 2.0
- 1 × VGA, 1 × HDMI 1.4, dual-display support
- Audio line-out with MIC combo
- 4-pin Phoenix terminal, 9 ~ 36 V support
- Windows 10 and Linux compatibility
- DC 9-36 V power supply, up to 220 W
These specifications translate into a machine that runs faster, stores more, connects easier, and survives tougher conditions, giving you the confidence to tackle any industrial computing challenge.
Specifications
| Chassis |
|
| Material/Structure |
Aluminum alloy + sheet metal fan heat dissipation |
| Color |
Black |
| Dimensions（L x W） |
243 x 208 x 79MM |
| Net weight |
KG |
| Installation |
Desktop/embedded |
| Motherboard |
|
| CPU |
Intel®LGA1151 /6、8、9th gen processor |
| Chipset |
Intel®Z390 |
| RAM |
2 x SODDR4, Max up to 64GB |
| Front Panel I/O |
|
| Power Switch |
1 x Power switch, 1 x Reset switch, 1 x AC LOSS switch（Restore AC loss power ON/OFF） |
| LED |
1 x HDD LED |
| USB |
2 x USB3.0，2 x USB2.0，In build 1 x USB2.0 |
| RemoteSwitch |
1 x 4pin Phoenix terminal (1 x power indicator signal, 1 x power switch signal) |
| SIM |
1 x SIM Card |
| Rear Panel I/O |
|
| Power Switch |
1 x Power button, 1 x one key restore |
| LED |
1 x HDD LED |
| Display |
1 x VGA(1920 x 1200@60Hz)，1 x HDMI1.4，Support dual display |
| USB |
6 x USB3.0 |
| COM |
4 x RS232/485 DB9，COM4 support RS232/422/485 |
| LAN |
6 x Intel I210AT 6 x Intel I210AT lan port，Including 4 x POE |
| Audio |
1 x Audio，Line out with MIC all in one |
| DIP switch |
2 x 6-bit DIP switches, RS232/422/485 switch through dip switch off + Jumper +BIOS setting |
| Power supply |
1 x 4P P=5.08mm Phoenix terminal，Support 9~36V |
| Storage |
|
| SATA |
1 x 2.5 inch HDD(IO board) |
| MSATA |
1 x MSATA(IO board) |
| SSD |
1 x M.2/SSD，Support Key-M，2280，NVME PCIEx4 SSD（on motherboard） |
| Expansion |
|
| WiFi |
1 x M.2，Support Key-E，2230，WiFi module |
| 5G |
1 x M.2，support Key-B，3042/3052，5G module |
| Support OS |
|
| Microsoft Windows |
Windows 10 |
| Linux |
Linux |
| Power Supply |
|
| Power Type |
DC 9-36VM |
| Max Power |
Max up to 220W |
| Power |
AC TO DC 120W above |
| Environment |
|
| Working Temp. |
-10℃～50℃ |
| Storage Temp. |
-20℃～70℃ |
